Overview

Make
FANUC
Model
Robodrill Alpha-21 MiA5
Type
Machining Centers, Vertical, (5-Axis or More)
Year
2013
Condition
Very Good
Stock #
57786

Specifications

CNC Control
yes
Type of CNC Control
Fanuc
# Axis
5
X
19.68 inches
Y
15.74 inches
Z
12.99 inches
Max Spindle RPM
10000
Taper
Big Plus 30
Weight
4409 pounds

Spec Sheet



Specifications:





anuc Robodrill Alpha D21MiA5 5 Axis Machining Center (2013)

X-Axis 19.68″
Y-Axis 15.74″
Z-Axis 12.99″
Table Size 25.59″ x 15.74″
Spindle Speed 10000 RPM
Spindle Taper BT-30 Big Plus
Spindle Motor 7.5 HP
Tools 21
Table Load Capacity 660 lbs.
Rapid Traverse Rates 2125 IPM
Max Tool Diameter 3.14″
Max Tool Length 9.84″
Max Tool Weight 6.6 lbs.
Machine Dimensions (L x W x H) 63.58″ x 80.3″ x 88″
Machine Weight 4409 lbs.
Spindle Torque 51.6 ft. lbs.
Tool Change Time (T – T / C – C) 0.9 / 1.6 Seconds



Request a Quote
